Fits 1990-1997 Ford Truck - Short Bed
The flange has a 6AN o-ring outlet and return port making the plumbing connections easy. The kit includes the assembled module, a new filter sock, flange o-ring, and the lock ring to complete your installation into your stock fuel tank. The 6061-T6 module flange has been anodized in a bright dip black finish that not only looks great but will also protect from undercar corrosion.
The flange has a 6AN o-ring outlet and return port making the plumbing connections easy. The kit includes the assembled module, a new filter sock, flange o-ring, and the lock ring to complete your installation into your stock fuel tank. The 6061-T6 module flange has been anodized in a bright dip black finish that not only looks great but will also protect from undercar corrosion.
- The 6061-T6 Aluminum fuel pump module is a high-pressure unit that flows 340 liters per hour (LPH) and is capable of supporting EFI (electronic fuel injection) engines producing up to 700 EFI horsepower.
- Includes a pre-calibrated fuel-level sending unit designed to work with the factory fuel gauge for this application
- 6AN o-ring outlet and return ports for easy plumbing connections
- Filter sock, flange O-ring, and fuel tank lock ring included to complete your installation
- Can be used with both carbureted and EFI (Electronic Fuel Injection) fuel systems depending on your need
- Both EFI and carbureted systems will need a bypass design regulator (We recommend the 12-879 or 12-880 Bypass Regulators for these installations. They can be used for both carbureted and EFI systems)
- The flange is bright dip black anodized for corrosion protection from undercar moisture.
Information:
Recommended Regulators (Holley 12-879, 12-880)Application Summary:
| Year | Make/Model |
|---|---|
| 1990-1997 | Ford F-150 |
| 1992-1994 | Ford F-250 |
| 1996-1997 | Ford F-250 |
| Attributes | |
| Application | 1990-1997 Ford Truck Short Bed |
| Average Flow Rating | 340 LPH |
| Brand | Holley Sniper, Holley Sniper EFI |
| Category | Air and Fuel Delivery |
| Country of Origin (Primary) | US |
| Emission Code | 5, 5 |
| Free Flow LPH | 340, 340 |
| Fuel Filter Included | Yes |
| Fuel Sending Unit Included | Yes |
| Fuel Tank Pressure Sensor Included | No |
| Fuel Type | Gasoline/E85 Compatible, Gasoline/E85 Compatible |
| Gasket Or Seal Included | Yes |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| In Tank or External | In Tank |
| Inlet Quantity | One, One |
| Inlet Size | 6 AN, 6 AN |
| Life Cycle Status Code | Available to Order |
| Lock Ring Included | Yes |
| Material | 6061-T6 Aluminum, 6061-T6 Aluminum |
| Negative Ground | Yes |
| Outlet Quantity | One, One |
| Outlet Size | 6 AN, 6 AN |
| Part Type | Fuel Pump Module Assembly |
| Product Type | Fuel Pump Module, Fuel Pump Module |
| Pump Type | Electric |
| Regulator Included | No |
| Resistance Ohms Empty | 22.5 82, 22.5 82 |
| Resistance Ohms Full | 145 82, 145 82 |
| Sale Category | Air and Fuel Delivery |
| SDR Required Flag | N |
| Strainer Included | Yes |
| Sub Category | Fuel Pumps and Related Components |
| Universal Or Specific Fit | Specific |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| Wire Harness Included | Yes |
| GTIN | 00090127122273 |
