Hi-Ram Sheet Metal Fabricated Intake Manifold LS1/LS2/LS6 92mm Throttle Body opening + Fuel Rail Kit Black with Sniper EFI Logo - Now includes mounting provision for MAP sensor on rear of Intake plenum. Use GM #12592525 or equivalent.
Holley is now offering cost effective fabricated intake manifolds for LS, Small Block Chevy and Small Block Ford engines in carbureted and EFI versions.
Holley is now offering cost effective fabricated intake manifolds for LS, Small Block Chevy and Small Block Ford engines in carbureted and EFI versions.
- Provision for MAP sensor located on rear of plenum
- Includes 3/8" fuel rail kits (Sniper logo laser engraved)
- 3mm (1/8") thick T6061 sheet aluminum construction for maximum durability
- Sniper intake will only accept EV1 style injectors
- 100% TIG welded for strength and durability
- Intake runners with tapered top is designed to increase air velocity and more evenly distribute airflow to all 8 cylinders improving performance and throttle response
- Product includes all gaskets and hardware for a hassle-free installation
- 92mm throttle bore opening for increased air flow
- Black finish creates stealthy under-hood styling
Information:
*** This intake is designed to work with stock LS heads. The use of some aftermarket cylinder heads may result in port misalignment ***| Attributes | |
| Basic Operating RPM Range | 2500-7000, 4500-7500 |
| Brand | Holley Sniper EFI, Holley Sniper EFI |
| California Proposition 65 | Yes |
| Carburetor Flange | N/A |
| Carburetor Quantity | N/A |
| Category | Air and Fuel Delivery, Intake Manifolds |
| Category Filter | Intake Manifolds |
| Clearance Category | Intake Manifolds |
| CNC Ported | No |
| Color | Black, Black |
| Construction | Fabricated, Fabricated |
| Country of Origin (Primary) | CN |
| Deck Height | 9.24 |
| EGR Port | No |
| Emission Code | 4, 4, Off Road |
| Engine | GM LS1/LS2/LS6, GM LS1/LS2/LS6 |
| Finish | Black |
| Flange Style | N/A |
| Front Height | 8.267 inch |
| Front Maximum Height | 8.267, 8.267 |
| Fuel Injectors Included | No |
| Fuel System Type | EFI, EFI |
| Gasket Or Seal Included | Yes, Yes |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Injector Style Provision | LS1/LS6 EV1 Jetronic, LS2 EV6 USCAR |
| Life Cycle Status Code | Available to Order |
| Manifold Type | Fabricated, Fabricated |
| Material | Aluminum |
| NAFTA Preference Criterion Code | B |
| Part Type | Engine Intake Manifold, Engine Intake Manifold |
| Plenum Finish | Black, Black |
| Product Type | Intake Manifold, Intake Manifold |
| Rear Height | 7.559 inch |
| Rear Maximum Height | 7.559, 7.559 |
| Recommended Use | Forced Induction, Forced Induction |
| RPM Power Band | 2500-7000 RPM |
| Runner Length | 4.921" (125mm), 4.921" (125mm) |
| Sale Category | Air and Fuel Delivery |
| SDR Required Flag | N |
| Single Or Dual Plane Type | Single |
| Style | EFI, EFI |
| Sub Category | Cylinder Block Components, Cylinder Block Components |
| Throttle Body Gasket Included | Yes |
| Throttle Bore | 92mm, 92mm |
| Vacuum Ports | (3) 1/8"-28BSPT & (1) 1/4"-19BSPT, (3) 1/8"-28BSPT & (1) 1/4"-19BSPT |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| GTIN | 00090127044933 |
