Circle Track Racing Ignition featuring a quick reset high RPM recall.
Based on the superior design of the MSD 6CT, the 6CT PRO adds another offering to MSD's line of technologically advanced ignitions for circle track racing. Packed with legendary MSD Ignition power, the 6CT PRO offers a slew of features. A large digital LED display makes it easier than ever to see the rev limiter setting when dialing it in using the laser etched rotary dials on the face of the unit.
Based on the superior design of the MSD 6CT, the 6CT PRO adds another offering to MSD's line of technologically advanced ignitions for circle track racing. Packed with legendary MSD Ignition power, the 6CT PRO offers a slew of features. A large digital LED display makes it easier than ever to see the rev limiter setting when dialing it in using the laser etched rotary dials on the face of the unit.
- Reverse polarity and overheat protection provide ultimate reliability
- Fully potted housing to stand up to demanding race conditions
- Highest RPM recording can quickly be reset with an external momentary switch
- Full delivery of spark energy down to 6 volts battery supply
- LED display shows rev limit, highest RMP turned, cylinder select, start retard, battery voltage and can be set to tach mode
- Records highest RPM the engine turned for last 20 minutes of run time
- MSD’s smoothest rev limiter yet! Won’t upset the chassis and easy on parts
- Easy setup of features with three rotary dials on the face of the unit
- Highly efficient, low current draw for extended battery life
- 0.8 Amps per 1,000 RPM
- Works on 4, 6 and 8 cylinder engines
- Single plug-in connector for clean wiring
- 535V w/ Blaster Coil / 550V w/ HVC Coil PN 8250
- Large, easy to read LED display
- Built-in Start Retard adjustable in 0⁰, 10⁰ or 20⁰ increments for quick, easy starts and extend starter life
Information:
1. High RPM recording can be quickly reset with a “customer supplied” momentary switch. 2. Not for use in series where tech officals require a high RPM recall reading.| Attributes | |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Red |
| Connector Gender | Male |
| Connector Quantity | 1 |
| Country of Origin (Primary) | US |
| Current Draw | .8 Amp per 1000 RPM, 0.8 Amps per 1,000 RPM |
| Dimensions | 7.89"L x 4.00"W x 1.87"H, 7.89L x 4.00W x 1.87H |
| Emission Code | 4, 4, Off Road |
| Features | Start Retard, Start Retard |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511804000 |
| Hazardous Material Code | N |
| Height | 1.87 |
| Ignition Type | Performance |
| Item Weight | 2.500 lbs. |
| Length | 7.89 |
| Life Cycle Status Code | Available to Order |
| Maximum RPM | 12,000 |
| Mount Type | Surface Mount, Surface Mount |
| Mounting Hardware Included | Yes, Yes |
| NAFTA Preference Criterion Code | B |
| Part Type | Ignition Control Module |
| Primary Voltage | 135mJ w/ Blaster Coil; 150mJ w/ HVC Coil, 535V w/ Blaster Coil / 550V w/ HVC Coil PN 8250 |
| Product Type | Ignition, Ignition |
| RPM | 12000 |
| RPM Range | 12,000 RPM |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Secondary Voltage | 45000, 45,000 Volts |
| Series | 6-Series Ignitions |
| Spark Duration | 20 Degree Crankshaft Rotation |
| Spark Energy | 135mJ w/ Blaster Coil; 150mJ w/ HVC Coil, 135mJ w/ Blaster Coil / 150mJ w/ HVC Coil PN 8250 |
| Spark Energy (mJ per spark) | 135 w/ Blaster Coil / 150 w/ HVC Coil PN 8250 |
| Spark Series Duration | 20° Crankshaft Rotation, 20° Crankshaft Rotation |
| Sub Category | Control Modules, Control Modules |
| Subcategory | Ignition Boxes |
| Terminal Gender | Male |
| Terminal Quantity | 12 |
| Voltage | 6-18 V |
| Voltage Required | 6 to 18 Volts, 6-18 |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| Weight | 2.5 lbs., 2.5 |
| Width | 4 |
| GTIN | 00085132064281 |
