Universal - Add To Any MSD 6-Series Ignition
The sturdy metal housing of the High Vibration Coil is completely potted with a premium grade epoxy to completely encase the coil's primary and secondary windings.
The sturdy metal housing of the High Vibration Coil is completely potted with a premium grade epoxy to completely encase the coil's primary and secondary windings.
- Improved output coil for electronic ignitions, and MSD Ignitions (ballast resistor required for points)
- Metal canister is encased with epoxy to protect the windings from high vibration applications
- CARB E.O. Approved
- 100:1 turns ratio and lower primary resistance produce high voltage output
Information:
CARB EO: D-40-37| Attributes | |
| ASIN | B00029JLAY |
| Brand | MSD, MSD |
| C.A.R.B. EO # | D-40-37 |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Black, Black |
| Country of Origin (Primary) | CN |
| Emission Code | 1, 1, Legal US |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Hazardous Material Code | N |
| Inductance | 8 mH |
| Inductance (mH) | 8 |
| Life Cycle Status Code | Available to Order |
| Maximum Voltage | 45000, 45,000 Volts |
| NAFTA Preference Criterion Code | B |
| Part Type | Ignition Coil |
| Peak Current | 140 mA, 140 |
| Primary Resistance | .700 ohms, .7 OHMs |
| Product Type | Ignition Coil, Ignition Coil |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Secondary Resistance | 4.5K ohms, 4.5K |
| Series | Blaster Performance Coils |
| Spark Duration | 350 uS, 0.35 |
| Sub Category | Ignition Coil |
| Subcategory | Coils and Parts |
| Turns Ratio | 100:1, 4.167361111111111 |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| Weight | N/A, 2.00 Lbs |
| GTIN | 00085132082223 |
