Universal - Use with Holley or MSD EFI Systems
Unique elongated mounting holes accommodate IGN-1A mounting brackets or allow it to bolt in place of an LS coil with 72mm bolt spacing. The MSD Smart Coil will bolt right onto Holley LS cast aluminum valve covers for a super clean look. Available in red or black.
Unique elongated mounting holes accommodate IGN-1A mounting brackets or allow it to bolt in place of an LS coil with 72mm bolt spacing. The MSD Smart Coil will bolt right onto Holley LS cast aluminum valve covers for a super clean look. Available in red or black.
- Built-in ignitor for compatibility with Holley EFI and many other aftermarket ECU’s
- Same wiring pinout as other IGN-1A coils for easy plugin upgrades
- Direct bolt-on to Holley cast aluminum LS valve covers with 72mm bolt spacing
- Elongated mounting holes to allow direct replacement of IGN-1A coils and will bolt in place of factory LS 1/2/3/6/7 coils with 72mm bolt spacing
- Maximum operating voltage of 17 volts – for compatibility with both 12 volt and 16 volt electrical systems found in many performance/race applications
- Available in red or black to match your build
- Contains two terminated harnesses with 7-pin connector for easier plug-in to Holley LSx main harness or factory GM LSx harness
- The harnesses are labeled for different engine types for GM and Ford cylinder banks even Holley universal coil near plug harness
- More spark energy than any other IGN-1A smart coil on the market for maximum fuel burn during combustion sequence
Information:
The supplied connectors and pins are "Pull to Seat " This means that you need to insert the wire through the connector from the back, crimp the pin and pull it back into the connector for assembly. Always use proper crimping tools to ensure a proper connection.| Attributes | |
| Brand | MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Coil Type | Smart Coil, Smart Coil |
| Color | Black, Black |
| Country of Origin (Primary) | CN |
| Emission Code | 3, 4, Off Road |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Hazardous Material Code | N |
| Inductance | 5.2 mH |
| Inductance (mH) | 5.2 |
| Life Cycle Status Code | Available to Order |
| Maximum Voltage | 50,000 Volts, 50,000 |
| NAFTA Preference Criterion Code | B |
| Part Type | Ignition Harness |
| Peak Current | 201 mJ |
| Peak Current (mJ) | 201 |
| Primary Resistance | .55 Ohms, 0.55 |
| Product Type | Ignition Coil, Ignition Coil |
| Quantity | 8-pack, 8-pack |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Series | Smart Coils |
| Sub Category | Ignition Wire and Related Components |
| Subcategory | Coils and Parts |
| Turns Ratio | 69:1, 2.8756944444444446 |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| GTIN | 00090127077412 |
