Small Block Chevrolet - Gen III/IV - Adjustable Timing Pointer - Red
On some vehicles, the MSD Crank Trigger Kit may require slight modifications to accommodate special engine plates, pulley systems, etc.
On some vehicles, the MSD Crank Trigger Kit may require slight modifications to accommodate special engine plates, pulley systems, etc.
- Easy to install much like traditional MSD Crank Trigger Kits (use with ATI Balancer 917302 or 918852 but is also compatible with 917264 and 917242)
- Powerful magnets embedded in a 3/8” thick billet 6061-T6 aluminum trigger wheel
- Allows precise indexing by utilizing the 10 degree range on included timing pointer
- Most accurate way to trigger your electronic fuel injection (EFI)
- Rigid mounting that will not flex and cause timing fluctuation
- 3-wire Hall-Effect Sensor that is not easily susceptible to EMI/RFI Interference
Information:
On some vehicles, the MSD Crank Trigger Kit may require slight modifications. This kit is designed to be used with the ATI Harmonic Balancer 917302 or 918852 but is also compatible with 917264 and 917242. This kit is also compatible with Meziere water pump WP333 and LSX Blocks.| Attributes | |
| Brand | MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition |
| Color | Red, Red |
| Country of Origin (Primary) | US |
| Diameter | 8 in., 8 |
| Emission Code | 4, 4, Off Road |
| Engine | GM Gen III/IV (LS), GM Gen III/IV (LS) |
| Harmonized Tariff Code (Schedule B) | 8511906040 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Make | Chevrolet, Chevrolet |
| Makes | Chevrolet |
| NAFTA Preference Criterion Code | B |
| Operating Voltage | 5-20 Volts, 5-20 |
| Part Type | Ignition Crank Trigger Kit |
| Product Type | Crank Trigger Kit, Crank Trigger Kit |
| SDR Required Flag | N |
| Sensor Type | Hall Effect, Hall Effect |
| Sub Category | Sensors |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| GTIN | 00090127130223 |
